Philips Semiconductors
UM_1SPP
BGB203 BT 2.0 Serial Port Profile Module User’s Guide
Results:
If any action other than the deletion of the local link key information, the
output will be as follows:
+BTPAR: <BDADDR>, <Link Key>
where,
<BDADDR> is the 12 digit ASCII coded hexadecimal Bluetooth
Device address of the remote Bluetooth device for which the link
key is associated. This value will be 12 digits (note that this
value is not preceded with the “ \x ” or the “ \X ” prefix). If there is
no link key currently stored, then this value will consist of a
Bluetooth address comprised of all zeros (“000000000000” – 12
zeros without the quotation marks).
<Link Key> is the 32 digit ASCII coded hexadecimal Bluetooth
link key that is associated with the specified Bluetooth device
address (prior parameter). This value will be 32 digits (note that
this value is not preceded with the “ \x ” or the “ \X ” prefix). If no
link key was assigned (or is present) then this value will consist
of a link key comprised of all zeros
(“00000000000000000000000000000000” – 32 zeros without
the quotation marks).
Immediately following the above output, the response will be the result
code (either OK or ERROR ).
If the deletion of a link key was performed then the result will simply
consist of the result code (either OK or ERROR ).
Example:
AT+BTPAR?
+BTPAR: 000000000000, 00000000000000000000000000000000
OK
AT+BTPAR=0
OK
AT+BTPAR=1, 123456789012
+BTPAR: 123456789012, 00000000000000000000000000000000
OK
AT+BTPAR=2
+BTPAR: 000123456789, 52FC670498F0E217A4DB83C86ACB9D9F
OK
+BTCAN – cancels any currently outstanding command
Description:
This command is cancels any outstanding command that was issued (in
? Koninklijke Philips Electronics N.V. 2005
All rights are reserved. Reproduction in whole or in part is prohibited without the prior
written consent of the copyright owner. The information presented in this document does
not form part of any quotation or contract, is believed to be accurate and reliable and may
be changed without notice. No liability will be accepted by the publisher for any
consequence of its use. Publication thereof does not convey nor imply any license under
patent- or other industrial or intellectual property rights.
Date of release:21 Dec 2005
Published in The Netherlands
